Toyota Motor Corporation's W family is a family of RWD/4WD transmissions built by Aisin. Physically, these transmissions have much in common (like the bell housing-to-body bolt pattern) with other Aisin-built transmissions, like the Jeep AX-5 and the Toyota G-series. The W55, W56, W57, W58, and W59 are externally and internally very similar aside from the gear ratios.

W40[edit]

4-speed transmission offered in base model vehicles in the 1970s. Often referred to as a Celica or Corona steel case 4-speed.The housing is steel as opposed to aluminium in later W series boxes.

Ratios:

First Gear: 3.287:1
Second Gear: 2.043:1
Third Gear: 1.394:1
Fourth Gear: 1.00:1
Reverse: -4.091:1

T5, T50D Manual Transmission 5-speed 4.0L MA5 MERCON®-V Automatic Transmission Fluid PN QT-5-QM Synchromesh MTF, Mercon V ATF, MaxLife ATF TR3650 Manual Transmission 5-speed TR6060 Manual Transmission 6-speed MT82 Getrag Manual Transmission 6-speed SLF PN XT-M5-QS, Spec WSS-M2C200-C Available from dealer. Toyota W56 Transmission Parts & Rebuild Kits. Toyota's W56 five-speed transmission was a popular unit that came in both two- and four-wheel drive Toyota vehicles. Aug 05, 2013 Ok I have a 1986 SR5 runner with the manual W56 transmission. I've never owned a runner and want to do a change on all the fluids. And appropriate transmission fluid? I'm about to go back home to see the family and would like to take the runner with me so time is short. Your feedback would be appreciated. Toyota 4Runner Technical.

Applications (calendar years):

1971–1976 Toyota Celica
1970s Corona up to the *T132 chassis

W42[edit]

4-speed transmission.

Ratios:

First Gear: 3.579:1
Second Gear: 2.081:1
Third Gear: 1.397:1
Fourth Gear: 1.000:1
Reverse: ?

Applications (calendar years):

1980s Toyota pickups

W45[edit]

The W45 is a 4-speed variant of the W55 alloy case box. It replaced the steel case W40 around Oct 1980. It also came as a stock transmission in some of the 1981 base model Toyota RWD pickups.

The W45 case was made of aluminium alloy.

Ratios:

W56 Toyota 5 Speed Manual Transmission Clutch Fluid Change

First Gear: 3.566:1
Second Gear: 2.056:1
Third Gear: 1.384:1
Fourth Gear: 1.00:1
Reverse: -4.091:1

Applications (calendar years):1980~ RWD Toyota Cars

1981 Toyota Hilux (2WD only)
1980–1982 TX60 13T-U Chaser (Japan)
1980–1982 TX76 13T-U Cressida wagon (Japan)
1980–1982 TX50 13T-U Cresta^[1] (jdm)

W50[edit]

Often called the 'steel-case' transmission for its steel shell, in contrast to the later W-series transmissions' aluminium case. This transmission is mostly associated with early Celicas of the 1970s. It is also shorter from the bellhousing face to the transmission mount than the later aluminium case W-series transmissions, despite using the same mount.

Ratios:

First Gear: 3.287:1
Second Gear: 2.043:1
Third Gear: 1.394:1
Fourth Gear: 1.00:1
Fifth Gear: 0.853:1
Reverse: -4.039:1

Applications (calendar years):

1973–1981 Toyota Celica
1974–1981 Toyota Carina
1973–1981 Toyota Corona
1979–1981 Toyota Supra
1976–1982 Toyota Hilux (RWD only)

W51[edit]

Came in early 1980s CE71 Corolla wagon. Similar ratios as W52 except 5th

Composition is alloy.

Ratios:

1st gear 3.625
2nd gear 2.043
3rd gear 1.394
4th gear 1.000
5th gear 0.802
rev gear 4.039

Applications (calendar years):

Toyota Corolla E70 CE71/CE72 wagon behind 1839 cc 1C diesel engine (Japan).^[2]

W52[edit]

Used in Australian delivered 2WD SR5 Extra-Cab Hilux (YN57)

Composition is steel.

Ratios:

First Gear: 3.625:1
Second Gear: 2.043:1
Third Gear: 1.394:1
Fourth Gear: 1.00:1
Fifth Gear: 0.853:1
Reverse: -4.039:1

Applications (calendar years):1984–1988 2WD Hilux (AU)

W55[edit]

This was the first of the aluminium-cased W-series transmissions. The W55 replaced the steel-cased W50, reducing the vehicle weight by 10 kg. It features mostly in 4 cylinder powered vehicles.

Ratios:

First Gear: 3.566:1
Second Gear: 2.056:1
Third Gear: 1.384:1
Fourth Gear: 1.00:1
Fifth Gear: 0.85:1
Reverse: -4.091:1

Applications (calendar years):

1982–1983 Toyota Carina
1981 Toyota Celica (USA)
1981–1985 Toyota Celica (Australia)
1983 Toyota Corona
1981-1984 Toyota Cressida RX60 (Europe)
1986 Toyota Crown
1983 Toyota Chaser
1983–1995 Toyota Hilux/Pickup 2WD with 22R or 22R-E engine
2001–2005 Lexus IS 300 (JCE10) (US market only)

W56[edit]

A common truck transmission that came in 2-wheel and 4-wheel drive varieties.

Its ratios differ in comparison to the base W55 in the 1st and 2nd gears only; this is to allow a slightly heavier vehicle (truck) to get up to speed slightly quicker than if geared like a car.

This was most likely accomplished by taking the W55 base gears and changing the 1st and 2nd gear sets, as the rest of the transmission remains unchanged.

Marlin Czajkowski, owner and CEO of Toyota-specific California-based rock crawling company Marlin Crawler, Inc., invented and popularized an A-through-E nomenclature system for 1985–1995 USA-market W56 transmissions.^[3] These include the W56-A (1985), W56-B (1986–88), W56-C (1989–91), W56-D (1992), and W56-E (1993–95) variants of 4WD Toyota Hilux Pickup and 4Runner W56 transmissions. This system is used to distinguish between the five major design changes Marlin has identified throughout this year span. Diesel powered sedans and station wagons featured the W56 as well as some commercial class vehicles such as the Cressida 4 cylinder models.

Ratios:

First Gear: 3.954:1
Second Gear: 2.141:1
Third Gear: 1.384:1
Fourth Gear: 1.00:1
Fifth Gear: 0.85:1
Reverse: -4.091:1

Applications (calendar years):

W57[edit]

The W57 is sometimes designated as a 'close-ratio transmission'; however in its stock form it does not meet all the criteria for a Close-ratio box.

The ratio shift was accomplished by taking the W55 base ratios and changing the input shaft to intermediate shaft ratio by 7.9%, thus shifting 1, 2, 3 ratios higher by that amount (4th is direct 1:1).

Unlike in the W58 the 5th/overdrive gear set was changed to create a smaller rpm drop between 4th & 5th gears so as to remain close to the overdrive ratio seen in the other boxes.

The rest of the transmission remains unchanged.

Ratios:

First Gear: 3.285:1
Second Gear: 1.894:1
Third Gear: 1.275:1
Fourth Gear: 1.00:1
Fifth Gear: 0.861:1
Reverse: -3.768:1

Applications (calendar years):

1983–1986 Toyota Supra MK 2 in certain non-US markets.
1986 Toyota Crown
1986 Toyota Cressida
1982–1985 Toyota Celica (21R)

W58[edit]

It differs from the W57 in its fifth-gear ratio. This transmission is popular as a replacement for weak stock transmissions in other vehicles. It came in two varieties: the original found in the 1982–1989 non-turbo Supras, Celicas and Cressidas of the early 1980s; and the later version found in Mk3, Mk 4 Supras and LexusSC 300s.

Toyota lists a change from an alloy sandwich plate to a steel sandwich plate around 1989. The steel sandwich plate has some minor internal differences, and it is believed to be slightly stronger (some wider bearings, some wider gears, slightly different gear selection mechanism, etc.).

In theory the all-alloy version of the W58 should be exactly the same strength as any other all-alloy W-Series transmission.The steel plate version is considered much harder to find and worth approximately three to five times as much as an all alloy version.

The ratios and bolt patterns remain the same regardless of the sandwich plate used.

The W58 & W57 share the highest gearing and closest ratios (1st, 2nd, 3rd, and 4th (direct)) of the stock W-Series transmissions.

The ratio shift was accomplished by taking the W55 base ratios and changing the input shaft to intermediate shaft ratio by 7.9%, thus shifting 1, 2, 3 ratios higher by that amount. This also shifted the overdrive 5th gear higher by the same amount creating a wider and taller overdrive ratio.

The W58 is sometimes designated as a 'close-ratio transmission'; however, in its stock form it does not meet all the criteria for a close-ratio box.

Toyota engineers have shown favor to the W58 over the rest of the 'W' series by including it in so many models and even building a stronger version for higher powered applications.

Ratios:

First Gear: 3.285:1
Second Gear: 1.894:1
Third Gear: 1.275:1
Fourth Gear: 1.00:1
Fifth Gear: 0.783:1
Reverse: -3.768:1

Applications (calendar years):

1982–1985 Toyota Celica (US)
1986 Toyota Cressida
1986 Toyota Soarer
1982–1992 Lotus Excel
1992–1997 Lexus SC300

W59[edit]

A common truck transmission, this was the successor to the W56. Like the W56, it came in both 2-wheel and 4-wheel drive versions.

This model appears to have a combination of ratios used in older models of the W-series.

1st and 2nd are low ratios like in the W56 for use to get a heavy vehicle moving.
3rd ratio is the same as in the W57/W58 for a lower rpm drop between 3rd & 4th useful in high-speed acceleration.
4th is direct 1:1 as per design in these boxes.
5th seems to be the base W55 overdrive ratio.
